Insulation Resistance Tester

Name: Insulation Resistance Tester
Brand: TID POWER
Price: 1 USD

Buy cheap Insulation Resistance Tester product

Brand Name : TID POWER

Model Number : 593401

Certification : ISO9001:2008

Place of Origin : CN;SHA

MOQ : 10.0 Piece/Pieces

Price : Negotiate

Payment Terms : T/T, L/C

Packaging Details : suitable packing for export,; 1.Inside packing: a plastic bag or woven belt 2.Outside packing: carton box and pallet. 3.According customer requirement.

Application : Testing

Certificate : ISO 9001

DC voltage measurement : 0.1~1000 V±5%

Demention : 150 mm*180 mm

Weight : About 950 g

Short circuit current : 2 mA

Contact Now

Insulation Resistance Tester

Product:

1.The information of Insulation Resistance Tester

The insulation resistance tester is mainly used for preventive detection of insulation tools and appliances before live work , and is used with insulation detection electrodes .

2.Technical Data Sheet of Insulation Resistance Tester

No.	Character	Value
1	Output voltage	250v(0%+20%)	Measurement range	0.01~250MΩ±(3%+5 )
		500v(0%+20%)		0.01~500MΩ±(3%+5 )
		1000v(0%+20%)		0.01~100MΩ±(3%+5 ) 1.00~5.00GΩ±(5%+0.1G Ω ) 5.00~10.00GΩ±(10%+0.2G Ω )
		2500v(0%+20%)		0.1~2.00MΩ±(3%+5 ) 2.00~20.00GΩ±(5%+0.2G Ω ) 5.00~100.00GΩ±(10%+2GΩ )
2	short circuit current	2mA
3	DC voltage measuremen	0.1~1000V ±5%
4	AC voltage measurement	0.1~750V ± 1%
5	Continuity test	0.01 Ω~200Ω±5%
6	show	Dual display with analog bar and digital
7	Automatic shut-down	√
8	Continuity test	√
9	AC and DC voltage test	√
10	Under voltage indication	√
11	lock function	Data can be locked during insulation testing
12	Timing function	There is a time lock function during the insulation test
13	automatic discharge	When the load is capacitive, the meter will automatically discharge.
14	data comparison	√
15	data storage	√
16	Automatic calculation	Automatically calculate the polarization index (PI) of the measured object and the dielectric absorption rate (DAR) of the measured object
17	Power supply	6 pcs No.2 batteries
18	Dimensions	19014065mm
19	weight	About 950g
20	Security Level	EN6101-1, EN61557-1,EN61326-1,CAT. Ⅲ ,100V cat IV 600V

3 The pictures of rubber gloves inflator for test hot line tools for testing high voltage safe electric security tools
